SACMI – Box forming machines
The SACMI GD25 is a true revolution in carton box forming! This impressive machine for producing corrugated carton crates achieves an incredible speed of 45 pieces per minute, all within a compact design that saves space. Equipped with an adjustable mold, the GD25 is highly versatile and perfect for the fruit and vegetable sector. But that’s not all – in the version with automatic format change, the machine can adapt to various industrial applications.
The SACMI GD25 can be equipped with various pneumatic and mechanical accessories, offering flexibility and the capability to increase production capacity up to 60 pieces per minute! For those seeking additional functionality, there is also a Citrus mold version, enabling the production of platform crates with a lid and Citrus/P84.
This machine delivers the perfect combination of efficiency, speed, and adaptability, making it an ideal solution for those looking to elevate their operations. With the GD25, possibilities are endless!
Key Features:
The SACMI GD25 can be equipped with various pneumatic and mechanical accessories, offering flexibility and the capability to increase production capacity up to 60 pieces per minute! For those seeking additional functionality, there is also a Citrus mold version, enabling the production of platform crates with a lid and Citrus/P84.
This machine delivers the perfect combination of efficiency, speed, and adaptability, making it an ideal solution for those looking to elevate their operations. With the GD25, possibilities are endless!
Key Features:
- High flexibility
- Quick format change
- High output capacity
- Easy handling and accessibility
- Low noise levels
- High reliability
- Minimal maintenance
- Production speed: 45 (60) pcs/min
- Installed power: 7 kW
- Compressed air consumption: 30 nl/cycle at 6 bar
- Weight: 1400 kg
- Machine dimensions: 3000 x 2000 x 2000 mm
- Minimum box size: 190 x 300 x 60 mm
- Maximum box size: 600 x 600 x 250 mm
- Minimum blank size: 320 x 420 mm
- Maximum blank size: 1000 x 1220 mm
- Box types: without corners, platform, display
- Automatic box stacker SACMI TS43 or TS43 Imola
- Conveyor belt
The SACMI LF20 is a high-quality automated machine designed for carton lid application in the packaging industry. This machine offers a high level of precision and speed, with the capability to quickly adapt to different carton formats and lid types.
Key Features:
Key Features:
- Simple format and forming head change: Enables fast adjustment to different box types.
- Integration with external conveyor systems: The machine can operate independently or connect to other recognition and sorting systems.
- Multiple options for hot glue applicators: Provides flexibility in choosing gluing methods.
- Production speed: 15 pcs/min
- Installed power: 10 kW
- Compressed air consumption: 32 nl/cycle at 6/8 bar
- Weight: 1000 kg
- Machine dimensions: 2200 x 1300 x 2500 mm
- Carton dimensions:
- Minimum: 350 x 240 x 50 mm
- Maximum: 600 x 400 x 100 mm
- Blank dimensions:
- Minimum: 440 x 340 mm
- Maximum: 750 x 600 mm
Introducing the SACMI PB20, a top-of-the-line automatic machine designed for inserting polyethylene bags into boxes, offering an incredible production capacity of up to 20 units per minute! This machine is the perfect solution for all your packaging needs, whether it's fruit, vegetables, or industrial products. With its exceptional versatility and precision, the SACMI PB20 ensures top-quality packaging.
The SACMI PB20 utilizes advanced brushless motors that enable precise bag opening and fast insertion into the boxes. Whether it's cardboard or plastic packaging, this machine delivers outstanding efficiency. Thanks to sophisticated electronic control systems, the SACMI PB20 is adaptable for working with high-density (HDPE) and low-density (LDPE) polyethylene bags, allowing you to effortlessly handle all tasks.
·Key Features:
The SACMI PB20 utilizes advanced brushless motors that enable precise bag opening and fast insertion into the boxes. Whether it's cardboard or plastic packaging, this machine delivers outstanding efficiency. Thanks to sophisticated electronic control systems, the SACMI PB20 is adaptable for working with high-density (HDPE) and low-density (LDPE) polyethylene bags, allowing you to effortlessly handle all tasks.
·Key Features:
- Standalone operation: Ideal for inline production, with the ability to adjust for working with both cardboard and plastic packaging.
- Fast format change: Simple and quick format change using handles with millimeter counters and intuitive control via a color touchscreen display.
- Compact design: Robust stainless-steel frame with transparent safety doors equipped with FRID micro-switches, providing security and reliability.
- Production speed: 20 units/min
- Installed power: 18 kW
- Compressed air consumption: 3 nl/cycle at 6 bar
- Weight: 1,300 kg
- Machine dimensions: 3,100 x 2,300 x 2,200 mm
- Minimum box size: 300 x 200 x 100 mm
- Maximum box size: 600 x 400 x 650 mm
- Minimum roll size: 300 x 80 mm
- Maximum roll size: 650 x 500 mm
Introducing the SACMI TF12 EVO – the top choice for forming corrugated cardboard boxes with a capacity of up to 40 units per minute! This impressive machine is perfect for specific applications, such as packaging fruits, vegetables, and industrial products, offering incredible versatility and adaptability.
The SACMI TF12 EVO can be equipped with various pneumatic and mechanical attachments to perfectly match your needs. For even greater functionality, a Citrus mold version is available, which allows for forming boxes with a cover platform and Citrus/P84. This machine enables quick format changes and high flexibility, meaning it can easily adapt to different production requirements.
The SACMI TF12 EVO is ideal for companies looking for a combination of efficiency, reliability, and high output capacity. Join many satisfied customers and discover how this machine can enhance your production!
·Key Features:
The SACMI TF12 EVO can be equipped with various pneumatic and mechanical attachments to perfectly match your needs. For even greater functionality, a Citrus mold version is available, which allows for forming boxes with a cover platform and Citrus/P84. This machine enables quick format changes and high flexibility, meaning it can easily adapt to different production requirements.
The SACMI TF12 EVO is ideal for companies looking for a combination of efficiency, reliability, and high output capacity. Join many satisfied customers and discover how this machine can enhance your production!
·Key Features:
- High flexibility
- Quick format change
- Large output capacity
- Ease of operation and accessibility
- Low noise level
- High reliability
- Minimal maintenance
- Production speed: 40 units/min
- Installed power: 6.5 kW
- Compressed air consumption: 30 nl/cycle at 6 bar
- Weight: 1,400 kg
- Machine dimensions: 4,100 x 1,800 x 2,000 mm
- Minimum box size: 190 x 210 x 60 mm
- Maximum box size: 600 x 600 x 250 mm
- Minimum board size: 340 x 420 mm
- Maximum board size: 1,000 x 1,300 mm
- Automatic box stacker SACMI TS43 and TS43 IMOLA
- Conveyor belt
The SACMI TF22 TS is a true revolution in the world of forming TOP SEAL carton trays for fruits and vegetables! This advanced machine, equipped with innovative dual heads, achieves an astonishing speed of up to 50 trays per minute per head, making it highly efficient and fast. As the new generation of cutting-edge solutions, the TF22 TS not only meets the requirements of protective packaging but also ensures excellent resistance against unauthorized opening.
What makes this machine extraordinary is its ability to handle edge widths as small as just 10 mm, drastically reducing the size of the edge and maximizing the use of the processable sample. With the capacity to process large dimensions up to 700 x 500 mm, the TF22 TS provides incredible flexibility in forming trays of various sizes and geometries. This machine is the ideal solution for those seeking high precision, speed, and versatility in their production process.
·Key Features:
What makes this machine extraordinary is its ability to handle edge widths as small as just 10 mm, drastically reducing the size of the edge and maximizing the use of the processable sample. With the capacity to process large dimensions up to 700 x 500 mm, the TF22 TS provides incredible flexibility in forming trays of various sizes and geometries. This machine is the ideal solution for those seeking high precision, speed, and versatility in their production process.
·Key Features:
- Dual head forming
- Ability to process 2 different models simultaneously
- Mechanical synchronization for high assembly precision
- High output up to 50 trays per minute (per forming head)
- Extremely compact
- Fast format change
- Large capacity sheet loader
- Exceptionally ergonomic with full accessibility
- Production speed: 100 trays/min
- Installed power: 17 kW
- Compressed air consumption: 540 nl/cycle at 6 bar
- Weight: 1,500 kg
- Machine dimensions: 3,100 x 2,100 x 2,300 mm
- Minimum tray size: 60 x 60 x 25 mm
- Maximum tray size: 340 x 340 x 125 mm
- Minimum sheet size: 125 x 110 mm
- Maximum sheet size: 700 x 500 mm
- Tray type: External and internal fold
- The SACMI TF22 TS delivers the perfect combination of speed, precision, and flexibility, setting new standards in the carton tray forming industry. Don’t miss the opportunity to enhance your production process with this top-of-the-line solution!
SACMI TF22 represents a cutting-edge innovation in the forming of cardboard trays! This outstanding machine with a dual head achieves an incredible speed of up to 90 trays per minute per head. Equipped with a single motor and mechanical synchronization of all movements, the TF22 guarantees exceptional precision at high speeds.
The machine supports various output types – continuous, individual, stacked, etc. – and allows for a quick and agile format change, taking no more than 30 minutes per head. This is the ideal solution for managing small production batches, offering high efficiency with a compact design.
Key features:
The machine supports various output types – continuous, individual, stacked, etc. – and allows for a quick and agile format change, taking no more than 30 minutes per head. This is the ideal solution for managing small production batches, offering high efficiency with a compact design.
Key features:
- Dual forming head
- Capability to process 2 different models simultaneously
- Mechanical synchronization for high assembly precision
- High output of up to 90 trays per minute (per forming head)
- Exceptionally compact
- Quick format change
- High-capacity sheet feeder
- Extremely ergonomic with full accessibility
- Production speed: 180 trays/min (2 forming heads), 90 trays/min (1 forming head)
- Installed power: 10 kW
- Compressed air consumption: 18 nl/cycle at 6 bar
- Weight: 1500 kg
- Machine dimensions: 3500 x 2100 x 2000 mm
- Minimum tray size: 85 x 110 x 30 mm
- Maximum tray size: 400 x 265 x 120 mm
- Minimum sheet size: 130 x 160 mm
- Maximum sheet size: 550 x 425 mm
SACMI TF40 Imola is a true innovation in the world of packaging! This outstanding machine is specialized in forming platform boxes, boxes with reinforced corners, and boxes with with an impressive capacity of 40 pieces per minute. Equipped with an adjustable mold, the TF 40 Imola is the perfect choice for the fruit and vegetable sector, offering exceptional versatility and adaptability to various needs in the shaping of corrugated cardboard crates.
What makes this machine special is its ability to combine flexibility with high performance and quick format changes. It can be adapted to your specific requirements thanks to various pneumatic and mechanical attachments, allowing the assembly of boxes in even special formats.
For those looking for more, the TF 40 Imola also offers a version with a Citrus tank, enabling the formation of platform crates with a cover, reinforced corners, and Citrus/P84 crate types. This machine is the right choice for anyone looking to bring freshness and innovation to their production process!
Main features: • High flexibility
• Fast format change
• Large output capacity
• Easy operation and accessibility
• Low noise level
• High reliability
• Minimal maintenance
Technical data: • Production speed: 40 pcs/min
• Installed power: 10 kW
• Compressed air consumption: 45 nl/cycle at 6 bar
• Weight: 1700 kg
• Machine dimensions: 6000 x 1800 x 2000 mm
• Minimum box size: 200 x 280 x 60 mm
• Maximum box size: 600 x 600 x 250 mm
• Minimum plate size: 340 x 420 mm
• Maximum plate size: 1000 x 1300 mm
• Box type: without corners, with closed and open corner, and platform
ADDITIONAL OPTIONS:
• SACMI TS 43 and TS43 IMOLA automatic box stacker
• Conveyor belt
What makes this machine special is its ability to combine flexibility with high performance and quick format changes. It can be adapted to your specific requirements thanks to various pneumatic and mechanical attachments, allowing the assembly of boxes in even special formats.
For those looking for more, the TF 40 Imola also offers a version with a Citrus tank, enabling the formation of platform crates with a cover, reinforced corners, and Citrus/P84 crate types. This machine is the right choice for anyone looking to bring freshness and innovation to their production process!
Main features: • High flexibility
• Fast format change
• Large output capacity
• Easy operation and accessibility
• Low noise level
• High reliability
• Minimal maintenance
Technical data: • Production speed: 40 pcs/min
• Installed power: 10 kW
• Compressed air consumption: 45 nl/cycle at 6 bar
• Weight: 1700 kg
• Machine dimensions: 6000 x 1800 x 2000 mm
• Minimum box size: 200 x 280 x 60 mm
• Maximum box size: 600 x 600 x 250 mm
• Minimum plate size: 340 x 420 mm
• Maximum plate size: 1000 x 1300 mm
• Box type: without corners, with closed and open corner, and platform
ADDITIONAL OPTIONS:
• SACMI TS 43 and TS43 IMOLA automatic box stacker
• Conveyor belt
SACMI TS 43 IMOLA represents a true revolution in the world of automatic box stacking! This top-tier system, ideal for working with platform and fold-free boxes, achieves an incredible speed of up to 60 boxes per minute. With exceptional flexibility when combined with all box forming machines, the TS43 Imola impresses with its ability to stack single and double layers of boxes up to 600 x 800 mm in size, without any height restrictions.
With quick format changeovers and high stacking speeds, the TS43 Imola offers great versatility, whether used in fruit and vegetable packaging or in the industrial sector. Equipped with advanced conveyor belts, the system allows for smooth and precise box handling. For complete autonomy, there is also a version that operates independently with an integrated electrical panel and control board, enabling fully independent stacking.
The TS43 Imola model brings innovation to automatic box stacking! It handles boxes via vertical movement and electronically synchronized motor drives, providing an exceptionally efficient and high-performance solution. Whether connected to a SACMI box forming machine or operating independently, the TS43 Imola sets new standards in stacking precision and speed, making every process faster and more efficient than ever before!
Main features: • Maximum height: No restrictions
• Maximum speed: 60 boxes/min (double stacking)
• Installed power: 1 kW
• Weight: 500 kg
• Machine dimensions: 1100 x 4900 x 2000 mm
Harness the power and efficiency of the SACMI TS43 IMOLA to revolutionize your packaging process and elevate your production to a new level of excellence!
With quick format changeovers and high stacking speeds, the TS43 Imola offers great versatility, whether used in fruit and vegetable packaging or in the industrial sector. Equipped with advanced conveyor belts, the system allows for smooth and precise box handling. For complete autonomy, there is also a version that operates independently with an integrated electrical panel and control board, enabling fully independent stacking.
The TS43 Imola model brings innovation to automatic box stacking! It handles boxes via vertical movement and electronically synchronized motor drives, providing an exceptionally efficient and high-performance solution. Whether connected to a SACMI box forming machine or operating independently, the TS43 Imola sets new standards in stacking precision and speed, making every process faster and more efficient than ever before!
Main features: • Maximum height: No restrictions
• Maximum speed: 60 boxes/min (double stacking)
• Installed power: 1 kW
• Weight: 500 kg
• Machine dimensions: 1100 x 4900 x 2000 mm
Harness the power and efficiency of the SACMI TS43 IMOLA to revolutionize your packaging process and elevate your production to a new level of excellence!
- ADDITIONAL OPTIONS:Automatic stacking device SACMI TS 43 IMOLA
- Conveyor Belt
PREO – hot and cold gluing systems
PREO hot-melt applicators are among the top inovations on the international market for several reasons: easy use, production flexibility, convenient operations and maintenance costs, quick installation, easy programming, high safety standards, exceptional reliability and full integration with any packaging line.The range of Preo systems includes:
·serie Easy P (equipped with pneumatic pump) in the versions 5,10,15,20 Kg.
·serie Easy W (equipped with gear pump) in the versions 5, 10,15,20 Kg.
·serie Easy U5 e U8 (equipped with gear pump) for polyamide and reactive polyurethane (P.U.R.)
·serie Easy UBM for reactive polyurethane ( P.U.R.) adhesive in cartridges.
·serie Bulkmelter BM 20 and 200 for adhesives in drums with pressure plate.
·And the Millennium systems 30 e 50 for high viscosity.
Beside applicators Preo offers a complete range of automatic modules and guns for bead, point, spiral, spray and slot coating applications and thermo-heated hoses for hot-melt adhesives.
De-Ro can instal your system, give you qualified technical assistance and supplying you all the spare parts for your Preo systems.
Remember that choosing Preo means choosing quality!
AUTOMATION – Automation and handling systems
Our expertise in design and development enables us to create advanced automated plants and handling systems perfectly tailored to your packaging lines.Our industrial handling systems are designed and optimized according to your processes, workflows, local safety regulations, and the specific conditions of your packaging facility, including height restrictions and pathways between rooms.
We offer integrated handling and automation systems equipped with:
- Conveyor belts
- Sorting systems
- Lifting units
- By-pass and accumulation systems
Technical features:
- Customizable materials and components tailored to specific customer needs
- Handling of primary and secondary packaging, including unique shapes
- Management and control with integrated and easily integrable hardware and software systems
WRAP AROUND machines for wrapping packages with cardboard
Our WRAP AROUND carton packaging machines offer an outstanding solution that combines efficiency, reliability, and versatility. Every aspect of the machine, from design to execution, is carefully crafted to ensure maximum productivity and dependability.Thanks to their compact dimensions and multiple configuration options, our machines can be installed even in spaces with limited surface areas. The user-friendly control panel and quick format change significantly optimize daily operations, while premium-quality components and a robust frame guarantee long-lasting reliability, even under the most demanding working conditions.
The unique value of our WRAP AROUND machines lies in their versatility. They can be adapted to various container types and formats, including brick packs, glass and plastic bottles, vials, jars, and different multi-pack configurations.
In terms of sustainability, the WRAP AROUND system offers an exceptional solution. Carton wrapping minimizes material usage, and the carton itself is recycled, further reducing the ecological footprint.
Our machines seamlessly integrate into highly efficient automated systems, enabling continuous monitoring of packaging from the packing machine to the palletizer.
With our WRAP AROUND machines, your company will achieve superior productivity and sustainability in the production process. Contact us for more information and a customized quote. Discover how our solutions can enhance your business!
Features and Performance:
Dimensions: 5700 x 2250 x 2100 mm
Infeed height from the ground: 900 mm
Outfeed height from the ground: 850 mm
Power consumption: 15 kW - 400V - 25A
Weight: 2500 kg
Capacity: 25 boxes/min, 1500 boxes/h
- Compressed air: 400 nl/min - 7 bar
PALLETIZER – automatic palletizing system
Our offering includes sophisticated palletizing systems tailored to the specific needs of our clients. We provide palletizing robots in various configurations, including linear, Cartesian, and anthropomorphic designs.Each of our palletizing systems can be customized to ensure:
- Management of one or multiple packaging lines
- Specialized functions such as overlapping or placing covers
- Customized programming to meet specific customer requirements
Our palletizing systems can be integrated with:
- Pallet strapping machines
- Pallet stackers
- Cardboard sheet warehouses
- Pallet wrapping machines
- Inkjet printers and labeling units
- WRAP AROUND carton packaging machines
- Pallet strapping machines
- Box forming machines
- Speed: up to 780 cycles/hour
- Robot type: anthropomorphic or Cartesian
- Minimal maintenance interventions
- Gripping systems with vacuum suction cups
- Grippers and systems for handling boxes, pallets, and layers of cardboard
- With our palletizing solutions, we guarantee high efficiency and reliability that will enhance your production processes. Contact us for tailored advice and solutions that meet your specific needs!
PICK & PLACE machines
Our Pick & Place machines are designed to offer maximum flexibility in production. These machines can handle packaging of various shapes, heights, and volumes. They can also package different types of secondary packaging such as trays, American boxes, plastic crates, and more.The machine can incorporate automatic closure of American boxes, use of adhesive tape, or hot glue application, providing complete automation of the packaging process.
Our solution also includes high-speed Pick & Place robots that offer enhanced speed, flexibility, and precision, although they require higher investment. These robots are ideal for operations demanding high efficiency and accuracy.
We are capable of designing and manufacturing entire automated systems, including palletizing stations, following principles of maximum efficiency. Our team of experts ensures that each solution is tailored to the specific needs of your business, enabling you to achieve top productivity and quality.
Features and Performance:
- Stainless steel construction
- High flexibility for primary and secondary packaging
- Box sealing with adhesive tape or hot glue
- Easy to use
- Contact us for more information and custom offers. We are happy to assist in improving your production processes!
Automatic applicator for straws and spoons
We present our automatic applicator for straws and spoons – the ultimate solution for your production process! This machine ensures consistent efficiency with minimal maintenance, while its compact dimensions and easily accessible components make daily use and maintenance straightforward. It also allows seamless integration into any packaging line.The innovative design of the applicator enables handling various types of straws (straight, telescopic, U-type) and spoons (including paper and compostable) with exceptional positioning precision. Its robust construction, made from high-quality stainless steel, guarantees long-lasting operation and reliable performance in all working conditions.
Additionally, our applicator is equipped with a bypass function for packages without straws, adding to its flexibility. It integrates perfectly with automation systems and palletizers, providing an advanced and customizable solution to enhance the efficiency of your production process.
Features and Performance
- Dimensions: 2585 x 800 x 1050 mm
- Entry height from the ground: 900 mm
- Exit height from the ground: 900 mm
- Consumption: 10 kW - 400V - 25A
- Weight: 800 kg
- Capacity: 10,000 straws/hour, 18,000 straws/hour
- Compressed air: 150 nl/min - 6 bar
Automatic packaging in heat-shrinkable foil
Our automatic shrink film packaging machine provides a highly efficient solution for various types of packaging, including jars, PET bottles, cans, and vials. It is ideal for industries such as beverages, food, chemicals, wine, spirits, cosmetics, detergents, wood, and textiles.This high-quality machine offers durability and ease of maintenance, along with low energy consumption thanks to advanced ovens. With a state-of-the-art sealing system, it supports different types of films and provides a capacity of 20 boxes/min. The machine allows for various packaging configurations:
- Film-only package
- Film and tray package
- Film and vertical pad package
- Film, tray, and vertical pad package
Ensure optimal productivity and quality while reducing costs and environmental impact with our solution. Contact us for a customized offer!
Features and Performance:
- Dimensions: 3500 x 4200 x 2100 mm
- Entry height from the ground: 900 mm
- Exit height from the ground: 900 mm
- Consumption: 21 kW - 400V - 37A
- Weight: 1500 kg
- Capacity: 20 boxes/min
- Compressed air: 400 nl/min - 6 bar
Contact us today and find out how we can meet all your needs in the corrugated and packaging industry!
Feel free to write to us and call us. We really love communicating with our clients.
Kućan Marof, Varaždinska ulica 104, 42000 Varaždin
